Specializing in high quality USB/SDI/AHD/CVBS/BT1120/IP/HDMI/CMOS/CCD camera modules from Korea, OEM customization - SOLUTION - IP camera module board

NEW

DCC-2W30

Digital H.264 IP WDR / HDR Video Module (1080p) . 1/2.8" 2MP Sony Color CMOS - IMX327LQR-C . 42x42mm Type 2 PCB Camera Boards . WDR, DSS(Sense-up), 3D-DNR/3DNR, TDN ICR, Auto Focus Motorized Zoom Lens, DC Auto IRIS, Network Protocol . Service video output, Select 1 (CVBS, AHD, TVI, or CVI) . Alarm, Audio (Line Level), RS485 UART Serial Out Port, SD Card, RTC, Lens Holder Available (M12 Lens Mount, D14 Lens Mount, C-mount, CS-mount) / DC12V or POE # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 2W30, DCC2W30 # Autofocus

DCC-2T0

Digital H.264 IP WDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 26x22mm Type 2 PCB Micro IP Camera Board . WDR, DSS(Sense-up) or 3D-DNR/3DNR, Network Protocol . DC5V or POE # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 2T0, DCC2T0

DCC-2S30

Digital H.264 IP WDR / HDR Video Module (1080p) . 1/2.3" 2MP Sony Pregius Color CMOS - IMX392LQR-C (Global Shutter) . 42x42mm Type 2 PCB Camera Boards . WDR, DSS(Sense-up), 3D-DNR/3DNR, TDN ICR, Auto Focus Motorized Zoom Lens, DC Auto IRIS, Network Protocol, Strobe Out . Alarm, Audio (Line Level), RS485 UART Serial Out Port, SD Card, RTC, Lens Holder Available (M12 Lens Mount, D14 Lens Mount, C-mount, CS-mount) / DC12V or POE # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 2S30, DCC2S30 # Autofocus, Auto Focus

DCC-2C0

Digital H.264 IP WDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 17Ø / 17phi Type 3 PCB Micro IP Camera Boards . WDR, DSS(Sense-up) or 3D-DNR/3DNR, Network Protocol . Audio (Microphone or Line Level) / DC12V or POE Refer to the DIB series for complete miniature cameras. # IP Board Camera # IP Module # Camera Module # PCB Module # 17 phi # DCC 2C0, DCC2C0

DCC-1Z30

Digital H.264 IP WDR / HDR Video Module (1080p) . 1/2" 2MP Sony Color CMOS - IMX385LQR-C . 42x42mm Type 2 PCB Camera Boards . WDR, DSS(Sense-up), 3D-DNR/3DNR, TDN ICR, Auto Focus Motorized Zoom Lens, DC Auto IRIS, Network Protocol . Service video output, Select 1 (CVBS, AHD, TVI, or CVI) . Alarm, Audio (Line Level), RS485 UART Serial Out Port, SD Card, RTC, Lens Holder Available (M12 Lens Mount, D14 Lens Mount, C-mount, CS-mount) / DC12V or POE # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 1Z30, DCC1Z30 # Autofocus

DCC-1M0

Digital H.264 IP WDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 42x42mm Type 1 PCB IP Camera Board . WDR, DSS(Sense-up) or 3D-DNR/3DNR, TDN ICR, Auto Focus Motorized Zoom Lens, DC Auto IRIS, Network Protocol . Alarm, Audio (Line Level), RS485 UART Serial Out Port, SD Card, RTC, Lens Holder Available (M12 Lens Mount, D14 Lens Mount, C-mount, CS-mount) / DC12V or POE # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 1M0, DCC1M0 # Autofocus

DCC-1K0

Digital H.264 IP WDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 32x32mm Type 1 PCB IP Camera Board . WDR, DSS(Sense-up) or 3D-DNR/3DNR, Network Protocol . Audio (Microphone), Lens Holder Available (M12 Lens Mount, C-mount, CS-mount) / DC12V or POE # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 1K0, DCC1K0

DCC-1H0

Digital H.264 IP WDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 17Ø / 17phi Type 3 PCB Micro IP Camera Boards . WDR, DSS(Sense-up) or 3D-DNR/3DNR, Network Protocol . DC12V or POE Refer to the DIB series for complete miniature cameras. # IP Board Camera # IP Module # Camera Module # PCB Module # 17 Phi # DCC 1H0, DCC1H0

EOL

DCC-1D0

Digital H.265 IP Video Module (1080p) . 32x32mm Type 1 PCB Camera Board . 3D-DNR, TDN ICR, Network Protocol . DC12V or POE . 1/2.8" 2MP Sony Color CMOS - IMX307 ** Discontinued. This model is replaced by DCC-960.

DCC-1A0

Digital H.264 IP WDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 28x28mm Type 1 PCB Micro IP Camera Board . WDR, DSS(Sense-up) or 3D-DNR/3DNR, Network Protocol . DC12V or POE Refer to the DIM series for complete miniature cameras. # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 1A0, DCC1A0

DCC-960

Digital H.264 IP WDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 32x32mm Type 1 PCB IP Camera Board . WDR, DSS(Sense-up) or 3D-DNR/3DNR, TDN ICR, Network Protocol . Lens Holder Available (M12 Lens Mount, C-mount, CS-mount) / DC12V or POE # IP Board Camera # IP Module # Camera Module # PCB Module # DCC 960, DCC960

EOL

DCC-6110

Digital IP Video Module (1080p) . 32x32mm Type 1 PCB Camera Board . 3D-DNR, TDN ICR, Network Protocol . DC12V or POE . 1/2.9" 2MP Sony Color CMOS - IMX322 ** Discontinued. This model is replaced by DCC-960.
