Specializing in high quality USB/SDI/AHD/CVBS/BT1120/IP/HDMI/CMOS/CCD camera modules from Korea, OEM customization - SOLUTION - AHD camera module board

NEW

ACC-2X0

Analog AHD WDR / HDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 32x32mm Type 1 PCB Micro AHD Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom . Built-in OSD Switch, UTC, Audio (Microphone) / DC12V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 2X0, ACC2X0 # TVI CVI Compatible

NEW

ACC-2Z0

Analog AHD Video Module (1080p) . 1/2.9" 2MP Color CMOS . 14x14mm Type 1 PCB Micro AHD Camera Board . DC 3.3V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 2Z0, ACC2Z0

ACC-2Q0

Analog AHD WDR Video Module (1080p) . 1/2.7" 2MP Color WDR CMOS . Ø19.4mm Type 1 PCB Micro AHD Differential Camera Board . UTC / DC 3.3V # AHD Board Camera # AHD Module # AHD Differential # Camera Module # PCB Module # ACC 2Q0, ACC2Q0 # TVI CVI Compatible

ACC-2N0

Analog AHD WDR / HDR Video Module (1944p) . 1/2.8" 5MP Sony Starvis Color CMOS - IMX335LQN-C . 32x32mm Type 1 PCB Micro AHD Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom . Built-in OSD Switch, UTC, Audio (Microphone) / DC12V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 2N0, ACC2N0 # TVI CVI Compatible

ACC-2M0

Analog AHD WDR / HDR Video Module (1080p) . 1/2.6" 2MP Onsemi Color CMOS - AR0234CS (Global Shutter) . 28x28mm Type 1 PCB Micro WDR Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom, Serial Protocol . Built-in OSD Switch, OSD port, RS232C UART Serial Port, UTC / DC5~12V Refer to the AHM series for complete miniature cameras. # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 2M0, ACC2M0 # Globalshutter # TVI CVI Compatible

ACC-2K0

Analog AHD WDR / HDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 26x22mm Type 1 PCB Micro AHD Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom, Serial Protocol . OSD Port, RS232C UART Serial Port / DC5V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 2K0, ACC2K0 # TVI CVI Compatible

ACC-2F0

Analog AHD WDR / HDR Video Module (1944p) . 1/2.8" 5MP Sony Starvis Color CMOS - IMX335LQN-C . 28x28mm Type 1 PCB Micro AHD Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom, Serial Protocol . Built-in OSD Switch, RS232C UART Serial Port, UTC, Audio (Microphone) / DC5~12V Refer to the AHM series for complete miniature cameras. # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 2F0, ACC2F0 # TVI CVI Compatible

ACC-2E0

Analog AHD WDR Video Module (1080p) . 1/2.7" 2MP Color WDR CMOS . Ø19.4mm Type 1 PCB Micro AHD Camera Board . UTC / DC 3.3V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 2E0, ACC2E0 # TVI CVI Compatible

ACC-1Y0

Analog AHD WDR / HDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 32x32mm Type 1 PCB Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, TDN ICR, D-zoom, Serial Protocol . Built-in OSD, OSD Port, UTC, RS232C UART Serial Port, Lens Holder Available (M12 Lens Mount, C-mount, CS-mount) / DC5~12V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 1Y0, ACC1Y0 # TVI CVI Compatible

ACC-1V0

Analog AHD Video Module (1080p) . 1/2.9" 2MP Color CMOS . Ø19x15.5mm Type 1 PCB Micro AHD Camera Board . DC 3.3V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 1V0, ACC1V0 # TVI CVI Compatible

ACC-1T0

Analog AHD Video Module (1080p) . 1/2.9" 2MP Color CMOS . Informal Custom PCB Camera Board . Lens Holder Available (M12 Lens Mount) / DC 5~15V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 1T0, ACC1T0 # TVI CVI Compatible

EOL

ACC-1L0

Analog AHD WDR Video Module (1080p) . Informal Custom PCB Camera Board . WDR, UTC, Lens Mount Available / DC 5~15V . 1/2.7" 2MP Color WDR CMOS ** Discontinued.

ACC-1G0

Analog AHD WDR / HDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 17Ø / 17Phi Type 3 PCB Micro AHD Camera Boards . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom, Serial Protocol . OSD Port, UTC, RS485 / DC5~12V Refer to the AHB series for complete miniature cameras. # AHD Board Camera # AHD Module # Camera Module # PCB Module # 17 Phi # ACC 1G0, ACC1G0 # TVI CVI Compatible

ACC-1E0

Analog AHD WDR / HDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 28x28mm Type 1 PCB Micro AHD Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom, Serial Protocol . Built-in OSD Switch, UTC, RS232C UART Serial Port / DC5~12V Refer to the AHM series for complete miniature cameras. # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 1E0, ACC1E0 # TVI CVI Compatible

EOL

ACC-1C0

Analog AHD Video Module (1080p) . Ø19.4mm Type 1 PCB Micro AHD Camera Board . UTC / DC 3.3V . 1/2.7" 2MP Color CMOS ** Discontinued. This model is replaced by ACC-2E0.

ACC-940

Analog AHD WDR / HDR Video Module (1080p) . 1/2.8" 2MP Sony Starvis Color CMOS - IMX327LQR-C . 42x42mm Type 1 PCB Camera Board . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, TDN ICR, D-zoom, Auto Focus Motorized Zoom Lens, DC Auto IRIS, Serial Protocol . Built-in OSD Switch, OSD Port, UTC, RS232C UART Serial Port, Lens Holder Available (M12 Lens Mount, D14 Lens Mount, C-mount, CS-mount) / DC12V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 940, ACC940 # Autofocus # TVI CVI Compatible

ACC-900

Analog AHD WDR / HDR Video Module (1944p) . 1/2.8" 5MP Sony Starvis Color CMOS - IMX335LQN-C . 21x21mm Type 2 PCB Micro AHD Camera Boards . WDR / HDR, DSS(Sense-up), 3D-DNR/3DNR, D-zoom, Serial Protocol . RS232C UART Serial Port, Lens Holder Available (M12 Lens Mount) / DC3.3V # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 900, ACC900 # TVI CVI Compatible

EOL

ACC-860

Analog AHD Video Module (1944p) . 1/2.8" 5MP Sony Starvis Color CMOS - IMX335LQN-C . 32x32mm Type 1 PCB Camera Board . 3D-DNR/3DNR, TDN ICR . Built-in OSD, OSD Port, Audio (Microphone), Lens Holder Available (M12 Lens Mount) / DC5~12V ** Discontinued. ACC-2N0 replaces this model. # AHD Board Camera # AHD Module # Camera Module # PCB Module # ACC 860, ACC860
